Emotron FDU Series User Manual

248 Menu List CG Drives & Automation 01-7491-01r0
81L Run Time
31128 122/17 2468 1128 Long, 1=1h EInt
31129 122/18 2469 1129 Long, 1=1m EInt
31130 122/19 246A 1130 Long, 1=1s EInt
81M Mains Time
31131 122/20 246B 1131 Long, 1=1h EInt
31132 122/21 246C 1132 Long, 1=1m EInt
31133 122/22 246D 1133 Long, 1=1s EInt
81N Energy 31147 122/36 247B 1147 Long, 1=1Wh EInt
81O Set/View ref 31135 122/24 246F 1135 Long, 1=0.001 EInt
81P VIO Status 31136 122/25 2470 1136 UInt, 1=1 UInt
81Q PT100 4,5,6
31137 122/26 2471 1137 Long, 1=1°C EInt
31138 122/27 2472 1138 Long, 1=1°C EInt
31139 122/28 2473 1139 Long, 1=1°C EInt
820
Trip Message
(Log 2)
31151
to
31189
122/40
to
122/78
247F
to
24A5
1151
to
1189
830
Trip Message
(Log 3)
31201
to
31239
122/90
to
122/128
24B1
to
24D7
1201
to
1239
840
Trip Message
(Log 4)
31251
to
31289
122/140
to
122/178
24E3
to
2509
1251
to
1289
850
Trip Message
(Log 5)
31301
to
31339
122/190
to
122/228
2515
to
253B
1301
to
1339
860
Trip Message
(Log 6)
31351
to
31389
122/240
to
123/23
2547
to
256D
1351
to
1389
870
Trip Message
(Log 7)
31401
to
31439
123/35
to
123/73
2579
to
259F
1401
to
1439
880
Trip Message
(Log 8)
31451
to
31489
123/85
to
123/123
25AB
to
25D1
1451
to
1489
890
Trip Message
(Log 9)
31501
to
31539
123/135
to
123/173
25DD
to
2603
1501
to
1539
8A0 Reset Trip L No 8 0/7 2008 8 UInt UInt
900
System Data
[900]
920
VSD Data
[920]
921 VSD Type 31037 121/181 240D 1037 UInt, 1=1 UInt
922 Software
31038 121/182 240E 1038 UInt UInt
31039 121/183 240F 1039 UInt UInt
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
