Emotron FDU Series User Manual

CG Drives & Automation 01-7491-01r0 Functional description 117
• Communication command Run and one or both of
RunR or RunL are set.
• Function enabled (Trip or Warning) in menu "[2647]
CPportFMode"
• No communication on the control panel port for
"[2648] CPportFTime" X seconds.
Control Panel port Fault Mode [2647]
Control Panel port Fault Time [2648]
Ethernet [265]
Settings for Ethernet module (Modbus/TCP, Profinet IO).
For further information, see the Fieldbus option manual.
IP Address [2651]
MAC Address [2652]
Subnet Mask [2653]
Gateway [2654]
DHCP [2655]
Fieldbus Signals [266]
Defines mapping for additional process values. For further
information, see the Fieldbus option manual.
FB S1/Wr1 - FB S8/Wr8 [2661]-[2668]
Used to create a block of parameters which can be written
via communication.
FB S9/Rd1 - FB S16/Rd8 [266A]-[266G]
Used to create a block of parameters which can be read via
communication.
FB Status [269]
Sub menus showing status of Fieldbus parameters. Please see
the Fieldbus manual for detailed information.
2647 CPportFMode
Default: Trip
Off 0 No supervision of the control panel.
Trip 1
The drive will trip after time set in
parameter [2648] if control panel is
removed.
Warning 3
The drive will give a warning after time
set in parameter [2648] if the control
panel is removed.
2648 CPportFTime
Default: 10.0 s
Range: 0.1 s - 15.0 s
NOTE: The Ethernet module must be re-booted to
activate the below settings. For example by toggling
parameter [261]. Non-initialized settings indicated by
flashing display text.
2651 IP Address
Default: 0.0.0.0
2652 MAC Address
Default:
An unique number for the Ethernet
module.
2653 Subnet Mask
Default: 0.0.0.0
2654 Gateway
Default: 0.0.0.0
2655 DHCP
Default: Off
Selection: On/Off
2661 FB S1/Wr1
Default: 0
Range: 0-65535
266A FB S9/Rd1
Default: 0
Range: 0-65535
NOTE: For Modbus all 16 fieldbus mappings can be
used either as read or write. Configuration of register
map is made menu [2661]-[266G] or Modbus range
42801-42816. Register read/write access is made in
Modbus range 42821-42836.
269 FB Status
