Emotron FDU Series User Manual

CG Drives & Automation 01-7491-01r0 Menu List 243
644 Logic 4 31096 121/240 2448 1096 UInt, 1=1 UInt
6441 L4 Expr ((1.2).3).4 43483 170/132 4D9B 19867 UInt UInt
6442 L4 Input 1 CA1 43484 170/133 4D9C 19868 UInt UInt
6443 L4 Op 1 & 43485 170/134 4D9D 19869 UInt UInt
6444 L4 Input 2 NOT1 43486 170/135 4D9E 19870 UInt UInt
6445 L4 Op 2 & 43487 170/136 4D9F 19871 UInt UInt
6446 L4 Input 3 Run 43488 170/137 4DA0 19872 UInt UInt
6447 L4 Op 3 . 43489 170/138 4DA1 19873 UInt UInt
6448 L4 Input 4 Off 43490 170/139 4DA2 19874 UInt UInt
6449 L4 Set Dly 0s 43491 170/140 4DA3 19875 Long, 1=1s EInt
644A L4 Res Dly 0s 43492 170/141 4DA4 19876 Long, 1=1s EInt
644B L4 Tmr Val 0s 43493 170/142 4DA5 19877 Long, 1=1s EInt
650 Timers [650]
651 Timer 1
6511 Timer1 Trig Off 43600 170/249 4E10 19984 UInt UInt
6512 Timer1 Mode Off 43601 170/250 4E11 19985 UInt UInt
6513 Timer1Delay 0s 43602 170/251 4E12 19986 Long, 1=1s EInt
6514 Timer1 T1 0s 43603 170/252 4E13 19987 Long, 1=1s EInt
6515 Timer1 T2 0s 43604 170/253 4E14 19988 Long, 1=1s EInt
6516 Timer1Value 0s 43605 170/254 4E15 19989 Long, 1=1s EInt
652 Timer2
6521 Timer2 Trig Off 43606 171/0 4E16 19990 UInt UInt
6522 Timer2 Mode Off 43607 171/1 4E17 19991 UInt UInt
6523 Timer2Delay 0s 43608 171/2 4E18 19992 Long, 1=1s EInt
6524 Timer2 T1 0s 43609 171/3 4E19 19993 Long, 1=1s EInt
6525 Timer2 T2 0s 43610 171/4 4E1A 19994 Long, 1=1s EInt
6526 Timer2Value 0s 43611 171/5 4E1B 19995 Long, 1=1s EInt
653 Timer3
6531 Timer3 Trig Off 43612 171/6 4E1C 19996 UInt UInt
6532 Timer3 Mode Off 43613 171/7 4E1D 19997 UInt UInt
6533 Timer3Delay 0s 43614 171/8 4E1E 19998 Long, 1=1s EInt
6534 Timer3 T1 0s 43615 171/9 4E1F 19999 Long, 1=1s EInt
6535 Timer3 T2 0s 43616 171/10 4E20 20000 Long, 1=1s EInt
6536 Timer3Value 0s 43617 171/11 4E21 20001 Long, 1=1s EInt
654 Timer4
6541 Timer4 Trig Off 43618 171/12 4E22 20002 UInt UInt
6542 Timer4 Mode Off 43619 171/13 4E23 20003 UInt UInt
6543 Timer4Delay 0s 43620 171/14 4E24 20004 Long, 1=1s EInt
6544 Timer4 T1 0s 43621 171/15 4E25 20005 Long, 1=1s EInt
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
