CG Drives & Automation 01-7491-01r0 Installation 35
Fig. 52 IP20 module sizes I/I69 with qty 3 x 3 Mains cables
and qty 3 x 3 motor cables.
PEBB 1
(Master)
PEBB 2
PEBB 3
Mains cables
Motor cables
L1, L2, L3
U, V, W
