TCP/IP LPR Port Printing Installation
c. Assign Print Server an IP address. At shell mode:
c.1. arp -s <the IP address you want to assign to
the Print Server> < Print Server 's Node
ID>
c.2. Execute tftp < Print Server 's IP> get
config.txt and quit tftp.
c.3. Edit the config.txt and modify the IP
address, subnet mask, and gateway IP.
When done, save the config.txt.
c.4. Execute tftp <Print Server 's IP> put
config.txt and quit tftp.
d. Start X-windows by typing startx at the shell
mode.
e. Open Printer Configuration.
f. Click New button.
g. Click Next button.
h. In the Queue Name field, type a user-defined
name.
i. In the Queue Type field, choose Unix Printer.
j. Click Next button.
k. In the Server field, type the IP of print server.
7 - 16
