Encore N150 User Manual

29
www.encore-usa.com
WAN Settings:
Scroll down to see more of the status information.
This section displays whether the WAN port is connected to a 3G / Cable / DSL modem. It
also displays the WAN IP address, Subnet Mask, ISP Gateway, MAC address and the
Primary DNS.
LAN Settings:
Scroll down to see this section, displays the ENHWI-3GN3 Router’s LAN ports
current information. It also shows whether the DHCP Server is enabled or disabled.
WLAN Settings:
Scroll down to see this section. This section displays the current WLAN configuration
settings. The wireless configuration details such as the SSID, Security settings, ESSID,
BSSID, Channel number and wireless clients connected info are briefly shown.

Encore N150 Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Receiver sensitivity	IEEE802.11n - MCS0@ -91dBm, MCS7@ -74dBm IEEE802.11g - 6Mbps@ -90dBm, 54Mbps@ -70dBm IEEE802.11b - 1Mbps@ -90dBm, 11Mbps@ -87dBm
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Interface	RJ-45, USB
Indoor range	100m
Outdoor range	300m
Frequency range	2.400 - 2.484 GHz
Power supply type	DC
Dimensions (WxDxH)	97 x 128 x 25 mm
Power requirements	12V
USB ports quantity	0
WLAN data transfer rates supported	157.5 Mbit/s
Non-operating relative humidity (non-condensing)	15 - 95 %
Channels quantity	13 channels
Media access protocol	CSMA/CA, ACK
Supported network protocols	TCP/IP, PPPoE/PPTP/L2TP, HTTP
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Antennas quantity	1
Antenna gain level (max)	2 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC, CE, RoHS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 45 °C

Weight and Dimensions

Weight	- g
