Encore N150 User Manual

8
www.encore-usa.com
2.2 Wall Mounting
Bottom View Showing Wall Mounts
The ENHWI-3GN3 is wall mountable. There are two mounting holes at the bottom of the
router. Find a proper spot where two nails or wall screws can be applied. The distance
between the two nails is 117 mm. Carefully mount the device onto the wall and make sure
the router is firmly in place.
2.3 Best Location
You can place ENHWI-3GN3 on a desk or other flat surface, or you can mount it on a wall.
For optimal performance, place your router in the center of your office (or your home) in a
location that is away from any potential source of wireless interference, such as a metal
wall or microwave oven. The preferred location should be close to a electrical power wall
outlet. If the antennas are not positioned correctly, performance loss can occur.

Encore N150 Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Receiver sensitivity	IEEE802.11n - MCS0@ -91dBm, MCS7@ -74dBm IEEE802.11g - 6Mbps@ -90dBm, 54Mbps@ -70dBm IEEE802.11b - 1Mbps@ -90dBm, 11Mbps@ -87dBm
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Interface	RJ-45, USB
Indoor range	100m
Outdoor range	300m
Frequency range	2.400 - 2.484 GHz
Power supply type	DC
Dimensions (WxDxH)	97 x 128 x 25 mm
Power requirements	12V
USB ports quantity	0
WLAN data transfer rates supported	157.5 Mbit/s
Non-operating relative humidity (non-condensing)	15 - 95 %
Channels quantity	13 channels
Media access protocol	CSMA/CA, ACK
Supported network protocols	TCP/IP, PPPoE/PPTP/L2TP, HTTP
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Antennas quantity	1
Antenna gain level (max)	2 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC, CE, RoHS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 45 °C

Weight and Dimensions

Weight	- g
