PlasmaQuant MS product family Installation and commissioning
35
Parameters Properties
Max. Water Pressure 500 kPa (72,5 psi)
Pressure at the instrument water inlet
Water purity Conductivity: permitted range
75-150 µS/cm, target range 100-120 µS/cm
(particle size < 0.1 mm)
pH: 7-9
Total Chlorine: < 20 mg/L (20 ppm),
total Nitrate: < 10 mg/L (10 ppm),
total Sulfate: < 100 mg/L (100 ppm)
Please observe the information provided in the recirculating chiller's operating
instructions.
The system must be filled with cooling water that has been mixed with a cooling water
additive which must be obtained from Analytik Jena. The preparation of the cooling
water is described in section "Changing the cooling water" on page 114. The coolant
additive prevents potential damage to the PlasmaQuant MS resulting from corrosion
and biological contamination. Damage to the device due to operation without coolant
additive is excluded from the warranty!
The PlasmaQuant MS water cooling system incorporates a flow switch to monitor
water flow and an inlet water valve. If a sufficient water flow rate is not maintained,
the plasma will be shut down, inhibiting ignition until sufficient water flow is restored.
4.1.6 Fore-line roughing pump
A fore-line roughing pump is included with the PlasmaQuant MS vacuum system.
Summary 8 Pump models
Device model Pump model Pump type
PlasmaQuant MS
PlasmaQuant MS Q
SV40BI Rotary vane pump
PlasmaQuant MS Elite S
PlasmaQuant MS Elite
XDS46i Oil-free pump with taper screw technology
The PlasmaQuant MS (Q) is equipped with an adsorption trap (with aluminum oxide).
This trap protects the ICP-MS against oil vapors from the fore-line pump SV40BI.
Aluminum oxide must be replaced once a year by the customer service department.
Summary 9 Fore-line roughing pump SV40BI
Parameters Properties
Protection class I
Voltage 200-240 V
Frequency 50/60 Hz
Line Current 10 A max.
Weight 43 kg
Oil capacity 1.0 L
