Cerabar M, Deltabar M, Deltapilot M / 4...20 mA HART Operation
Endress+Hauser 45
Operating keys on the display and operating module
Symbol Meaning
Error message "Service mode"
The device is in the service mode (during a simulation, for example).
Error message "Maintenance required"
Maintenance is required. The measured value remains valid.
Error message "Failure detected"
An operating error has occurred. The measured value is no longer valid.
Operating key(s) Meaning
O
– Navigate downwards in the picklist
– Edit the numerical values and characters within a function
S
– Navigate upwards in the picklist
– Edit the numerical values and characters within a function
F
–Confirm entry
–Jump to the next item
– Selection of a menu item and activation of the editing mode
O
and
F
Contrast setting of local display: darker
S
and
F
Contrast setting of local display: brighter
O
and
S
ESC functions:
– Exit the edit mode for a parameter without saving the changed value.
– You are in a menu at a selection level. Each time you press the keys simultaneously, you
go up a level in the menu.
