Technical data Deltabar PMD75B HART
72 Endress+Hauser
Storage temperature • Without LCD display: –40 to +90 °C (–40 to +194 °F)
Optional –54 to +85 °C (–65 to +185 °F)
• Without LCD display: –40 to +90 °C (–40 to +194 °F); optional –50 °C (–58 °F)
• With LCD display: –40 to +85 °C (–40 to +185 °F)
• Separate housing: –40 to +60 °C (–40 to +140 °F)
Operating altitude Up to 5 000 m (16 404 ft)
Climate class Class 4K4H (air temperature: –20 to +55 °C (–4 to +131 °F), relative humidity: 4 to 100 %)
satisfied as per DIN EN 60721-3-4.
Condensation is possible.
Atmosphere Operation in very corrosive environment
Anodic corrosion protection can be ordered as a "mounted accessory".
Degree of protection Test as per IEC 60529 and NEMA 250-2014
Housing and process connection
IP66/68, TYPE 4X/6P
Cable entries
• Gland M20, plastic, IP66/68 TYPE 4X/6P
• Gland M20, brass nickel plated, IP66/68 TYPE 4X/6P
• Gland M20, 316L, IP66/68 TYPE 4X/6P
• Thread M20, IP66/68 TYPE 4X/6P
• Thread G1/2, IP66/68 TYPE 4X/6P
• Thread NPT1/2, IP66/68 TYPE 4X/6P
• Dummy plug transport protection: IP22, TYPE 2
• Plug HAN7D, 90 deg. IP65 NEMA Type 4x
• Plug M12
When housing is closed and connecting cable is plugged in: IP66/67 NEMA Type 4X
When housing is open or connecting cable is not plugged in: IP20, NEMA Type 1
NOTICE
Plug M12 and plug HAN7D: incorrect mounting can invalidate the IP protection class!
‣
The degree of protection only applies if the connecting cable used is plugged in and
screwed tight.
‣
The degree of protection only applies if the connecting cable used is specified according
to IP67 NEMA Type 4X.
‣
The IP protection classes are only maintained if the dummy cap is used or the cable is
connected.
Process connection and process adapter when using the separate housing
FEP cable
• IP69 (on sensor side)
• IP66 TYPE 4/6P
• IP68 (1.83 mH
2
O for 24 h) TYPE 4/6P
PE cable
• IP66 TYPE 4/6P
• IP68 (1.83 mH
2
O for 24 h) TYPE 4/6P
