Appendix Ecograph T, RSG35
106 Endress+Hauser
Navigation Expert → Inputs → Universal inputs → Universal input x → Meas. val. corrct → Target
value
Direct access code: 220052-0xx
Examples: Universal input 1: 220052-000; Universal input 12: 220052-011
Description Enter the lower set point here (e.g. measuring range 0°C to 100°C: 0°C).
Only visible if signal = current or voltage.
User entry Number (max. 8 digits)
Factory setting 0
Actual value
Navigation Expert → Inputs → Universal inputs → Universal input x → Meas. val. corrct → Actual
value
Direct access code: 220053-0xx
Examples: Universal input 1: 220053-000; Universal input 12: 220053-011
Description Enter the lower value actually measured here (e.g. measuring range 0°C to 100°C:
measured value 0.5°C).
Only visible if signal = current or voltage.
User entry Number (max. 8 digits)
Factory setting 0
Meas. range end
Target value
Navigation Expert → Inputs → Universal inputs → Universal input x → Meas. val. corrct → Target
value
Direct access code: 220055-0xx
Examples: Universal input 1: 220055-000; Universal input 12: 220055-011
Description Enter the upper set point here (e.g. measuring range 0°C to 100°C: 100°C).
Only visible if signal = current or voltage.
User entry Number (max. 8 digits)
Factory setting 100
Actual value
