Technical data Ecograph T, RSG35
74 Endress+Hauser
Materials of desktop housing
• Housing half-panels: sheet steel, electrolytically plated (powder-coated)
• Side sections: aluminum extruded section (powder-coated)
• Section ends: colored polyamide
15.9 Display and operating elements
Operating concept The device can be operated directly onsite, or via remote configuration with the PC via
interfaces and operating tools (Web server, configuration software).
Integrated operating instructions
The device's simple control system enables you to perform commissioning for many
applications without the need for hard copy operating instructions. The device has an
integrated help function and displays operating instructions directly on screen if the
navigator (jog/shuttle dial) is pressed for longer than 3 seconds.
Local operation Display elements
Type
TFT color display
Size (diagonal screen measurement)
145 mm (5.7")
Resolution
VGA 307,200 pixels (640 x 480 pixels)
Backlight
70,000 h half value time (= half brightness)
Number of colors
262,000 viewable colors, 256 colors used
Viewing angle
Viewing angle: 130° vertical, 150° horizontal
Screen display
• Background color white
• Active channels can be assigned to up to 4 groups. These groups can be given a name
e.g. "Temp. boiler 1" or "Daily averages" so that they can be uniquely identified.
• Linear scaling
• Measured value history: quick retrieval of historical data with zoom function
• Preformatted screen displays such as horizontal or vertical curve presentation, bar graph
display or digital display.
