Ecograph T, RSG35 Appendix
Endress+Hauser 119
Description The duration between "On" and "Off" can be recorded. The duration is appended to the "Off"
event text (<hhhh>h<mm>:<ss>).
Power failure times do not affect the duration. If the digital channel was "on" before the
power failure and is still "on" after the power failure, the duration continues.
Only visible if function = control input, on/off event, event+operation time.
Options No, Yes
Factory setting No
Totalizer
Navigation Expert → Inputs → Digital inputs → Digital input x → Totalizer
Direct access code: 250013-00x
Examples: Digital input 1: 250013-000; Digital input 6: 250013-005
Description Initial setting for the totalizer. Useful when continuing measurements recorded to date
with an (electro)-mechanical counter.
Only visible if function = pulse counter, operational time, event+operation time or quantity
from time.
User entry Number (max. 15 digits)
Factory setting 0
Copy settings
Navigation Expert → Inputs → Digital inputs → Digital input x → Copy settings
Direct access code: 250200-00x
Examples: Digital input 1: 250200-000; Digital input 6: 250200-005
Description Copies settings from actual channel to selected channel.
Options No, Digital input x
Users can choose from all the available digital inputs.
Factory setting No
16.1.3 "Outputs" submenu
Setting up only required if outputs (e.g. relays) are to be used.
"Relay x" submenu
Navigation Expert → Outputs → Relay x
