Ecograph T, RSG35 Installation
Endress+Hauser 11
4.4 Storage and transport
Compliance with the permitted environmental and storage conditions is mandatory. For
precise specifications, see the "Technical data" section→ 63 of the Operating
Instructions.
Please note the following:
• Pack the device so that is protected against impact for storage and transport. The
original packaging provides optimum protection.
• The permitted storage temperature is –20 to +60 °C (–4 to +140 °F).
5 Installation
5.1 Mounting requirements
NOTICE
Overheating due to buildup of heat in the device
‣
To avoid heat buildup, please always ensure that the device is sufficiently cooled.
The device is designed for use in a panel in non-hazardous areas.
• Ambient temperature range–10 to +50 °C (14 to 122 °F)
• Climate class as per IEC 60654-1: Class B2
• Degree of protection: IP65, NEMA 4 at front / IP20 housing at rear
5.1.1 Installation dimensions
Please observe the installation depth of approx. 158 mm (6.22 in) for the device incl.
terminals and fastening clips.
• Panel cutout: 138 to 139 mm (5.43 to 5.47 in) x 138 to 139 mm (5.43 to 5.47 in)
• Panel strength: 2 to 40 mm (0.08 to 1.58 in)
• Angle of vision: from the midpoint axis of the display, 75° to the left and right, 65° above
and below.
• A minimum distance of 15 mm (0.59 in) mm (inch) between the devices must be
observed if aligning the devices in the Y-direction (vertically above one another). A
minimum distance of 10 mm (0.39 in) mm (inch) between the devices must be observed
if aligning the devices in the X-direction (horizontally beside one another).
• Securing to DIN 43 834
5.2 Mounting the measuring device
Mounting tool: For installation in the panel, all you need is a screwdriver.
