Ecograph T, RSG35 Technical data
Endress+Hauser 71
15.5 Performance characteristics
Response time
Input Output Time [ms]
Current, voltage, pulse Relay ≤ 550
RTD Relay ≤ 1150
TC
1)
Relay ≤ 1550
Cable open circuit detection, current input Relay ≤ 1150
Sensor error RTD, TC Relay ≤ 5000
Digital input Relay ≤ 350
1) If internal measuring point temperature compensation is used, otherwise values as for voltage
Reference operating
conditions
Reference temperature 25 °C (77 °F) ±5 K
Warm-up period 120 min.
Humidity 20 to 60 % rel. humidity
Hysteresis Can be configured for limit values in the setup
Long-term drift As per IEC 61298-2: max. ±0.1%/year (of measuring range)
15.6 Installation
Mounting location and
installation dimensions
The device is designed for use in a panel in non-hazardous areas.
