Appendix Ecograph T, RSG35
160 Endress+Hauser
Navigation Expert → Application → Signal groups → Group x → Display
Direct access code: 460018-0xx
Examples: Group 1: 460018-000; Group 4: 460018-003
Description Please select which data from the selected channel should be displayed.
Options Instantaneous value/state, Analysis x, Totalizer, Everything
Factory setting Instantaneous value/state
Grid divisions
Navigation Expert → Application → Signal groups → Group x → Grid divisions
Direct access code: 460019-0xx
Examples: Group 1: 460019-000; Group 4: 460019-003
Description Indicates the number of lines ("amplitude grid") that should be displayed. Example: display
of 0 to 100%: select 10 divisions, display 0 to 14pH: select 14 divisions.
Options 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20
Factory setting 10
Zoom
Navigation Expert → Application → Signal groups → Group x → Zoom
Direct access code: 460028-0xx
Examples: Group 1: 460028-000; Group 4: 460028-003
Description Defines the zoom that is shown in "Curves" or "Waterfall" display mode. This setting does
not affect other display modes (e.g. Curves in range, Bar graph etc.).
Options Do not display, Scroll display, Display blue, Display black, Display red, Display green,
Display violet, Display orange, Display cyan, Display brown
Factory setting Do not display
"E-mail" submenu
Navigation Expert → Application → E-mail
With Tele-Alarm option under
Expert → Application → Tele-Alarm → General → E-mail setup
Description Contains settings required if alarms are to be transmitted by e-mail.
Test the e-mail settings under Diagnostics → Simulation → E-mail.
