Micropilot FMR60B PROFINET with Ethernet-APL
4 Endress+Hauser
Important document information
Symbols Safety symbols
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or
fatal injury.
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or
fatal injury.
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in minor or
medium injury.
This symbol contains information on procedures and other facts which do not result in personal
injury.
Electrical symbols
Direct current
Alternating current
Direct current and alternating current
Ground connection
A grounded terminal which, as far as the operator is concerned, is grounded via a grounding system.
Protective earth (PE)
Ground terminals that must be connected to ground prior to establishing any other connections.
The ground terminals are located on the inside and outside of the device.
• Inner ground terminal; protective earth is connected to the mains supply.
• Outer ground terminal; device is connected to the plant grounding system.
Symbols for certain types of information and graphics
Permitted
Procedures, processes or actions that are permitted
Preferred
Procedures, processes or actions that are preferred
Forbidden
Procedures, processes or actions that are forbidden
Tip
Indicates additional information
Reference to documentation
Reference to graphic
1, 2, 3, ...
Item numbers
A, B, C, ...
Views
Hazardous area
Indicates the hazardous area
Safe area (non-hazardous area)
Indicates the non-hazardous area
