Endress+Hauser PROMAG 33 - Brief Operating Instructions; Safety Instructions; Mounting and electrical connection; Commissioning

Brief Operating Instructions
With the following instructions, you may configure your measuring instrument quickly
and easily:
Safety instructions → see page 5
↓
Mounting and electrical connection
• Mounting → see page 9
• Electrical connections → see page 21
↓
Commissioning → see page 34
↓
Operation → see page 35 ff.
↓
Display configuration
• Language → see page 68
• Contrast → see page 68
• Assign line 1 → see page 67
• Assign line 2 → see page 67
• Number of decimal digits → see page 68
continued: next column
ba009y83
Engineering units → see page 47 ff.
↓
Configuration of outputs
Current output
• Full scale values → see page 49, 51
• Current span → see page 51
Pulse / Frequency output
• Operation mode → see page 53
• Pulse value → see page 53
• Pulse width → see page 53
• Full scale frequency → see page 54
• Full scale value → see page 55
• Output signal → see page 56
↓
Relay outputs → see page 58 ff.
↓
More complex applications
require programming of additional functions.
The appropriate key works and cross-
references are found on the following pages:
• Functions at a Glance → see page 117
• Index → see page 121
• Operating matrix → see page 37
↓
For optimum measuring results
• Creep suppression → see page 72
• Empty Pipe Detection → see page 73
Promag 33
2 Endress+Hauser
