Commissioning Smartec S CLD132
44 Endress+Hauser
• Enter the values in the order of increasing concentration (see the following example).
mS/cm % °C
240 96 60
380 96 90
220 97 60
340 97 90
120 99 60
200 99 90
Coding Field Selection or range
(factory settings bold)
Display Info
K
Function group
CONCENTRATION
Settings for concentration measurement. Four
fixed and four editable concentration fields are
stored in this function group.
K1
Select concentration
curve to be used to
calculate the display
value
NaOH 0... 15 %
H
2
SO
4
0 ... 30 %
H
3
PO
4
0 ... 15 %
HNO
3
0 ... 25 %
Tab 1 ... 4
The user tables 2 ... 4 can only be selected if
the instrument is equipped with the remote
measuring range switching.
K2
Select correction
factor
1
0.5 ... 1.5
If required, select a correction factor (only
available for the user tables).
K3
Select table to be
edited
1
1 ... 4
When editing a curve, another curve should
be used to calculate the current display values
(see K1).
Selections 2 ... 4 are only available with the
remote measuring range switching.
K4 Select table option
read
edit
This selection applies to all concentration
curves.
K5
Enter number of
reference triplets
4
1 ... 16
Each triplet consists of three numeric values.
K6 Select triplet
1
1 ... number of triplets in K4
assign
Any triplet can be edited.
If "assign", go to K10.
K
CONCENTRA
K1
act.curve
NaOH
K2
Conc.Fact
1
K3
editCurve
1
K4
Table
read
K5
No. Elem.
4
K6
Sel.Elem.
1
