Smartec S CLD134 Commissioning
Endress+Hauser 37
!
Note!
You must perform an air set before installing the sensor. To do so, refer to the chapter "Calibration".
26. In O2, select the linear characteristic.
Confirm your selection by pressing ENTER.
lin = linear (1)
sim = simulation (2)
27. In O211, select the current range for your output,
e.g. 4 ... 20 mA.
Confirm your selection by pressing ENTER.
4...20mA
0...20mA
28. In O212, enter the conductivity corresponding to the
minium current value at the transmitter output, e.g.
0 μS/cm.
Confirm your entry by pressing ENTER.
0.00 μS/cm
0.00 μS/cm ...
2000 mS/cm
29. In O213, enter the conductivity corresponding to the
maximum current value at the transmitter output,
e.g. 930 mS/cm.
Confirm your entry by pressing ENTER.
The display returns to the initial display of the
"Output" function group.
2000 mS/cm
0.0 μS/cm ...
2000 mS/cm
30. Press the PLUS and MINUS keys simultaneously to
return to measuring mode.
Input Selection or range
(factory setting bold)
Display
O2
Sel.Type
lin
O211
Sel.Range
4-20
O212
µS/cm
0/4mA
0
O213
mS/cm
20 mA
930
