Smartec S CLD134 Troubleshooting
Endress+Hauser 67
9.3 Process-specific errors
Use the following table to locate and correct errors.
E063 Below current output range 1 Check measured value and current output
assignment (function group O).
yes no
E064 Current output range 1 exceeded yes no
E065 Below current output range 2 Check measured value and current output
assignment.
yes no
E066 Current output range 2 exceeded yes no
E067
Limit contactor set value exceeded Check measured value, limit setting and metering
devices.
Only available with R1 = alarm + limit value or limit
value.
yes no
E077
Temperature outside
α value table
range
Check measurement and tables. yes no
E078
Temperature outside concentration
table
yes no
E079
Conductivity outside concentration
table
yes no
E080
Current output 1 parameter range too
small
Spread current output. no no
E081
Current output 2 parameter range too
small
Spread current output. no no
E100 Current simulation active no no
E101
Service function yes Switch service function off or switch instrument off
and back on.
no no
E102 Manual mode active no no
E106 Download yes Wait for download to end. no no
E116 Download error Repeat download. no no
E150
Distance between temperature values
in
α value table too small
Enter correct values in
α value table (minimum
distance of 1 K required between temperature
values).
no no
E152 Live Check alarm Check sensor and connection. no no
Error no. Display Tests and / or measures Alarm contact Error current
Factory User Factory User
Error Possible cause Tests and / or remedial measures Equipment, spare parts, personnel
Display deviates from
reference measurement
Calibration faulty Calibrate instrument according to chapter
"Calibration".
Calibration solution or sensor certificate
Sensor soiled Clean sensor. See chapter "Cleaning conductivity sensors".
Incorrect temperature measurement Check temperature value on instrument
and reference unit.
Temperature measuring instrument,
precision thermometer
Incorrect temperature compensation Check compensation method (none / ATC
/ MTC) and compensation type
(linear/substance/user table).
Please note: transmitter has separate
calibration and operating temperature
coefficients.
Reference instrument calibration faulty Calibrate reference instrument or use
calibrated instrument.
Calibration solution, operating instructions
of reference instrument
Incorrect ATC setting on reference
instrument
Compensation method and compensation
type must be identical on both instruments.
Operating instructions of reference
instrument
