Commissioning Smartec S CLD134
54 Endress+Hauser
Assignment of binary inputs
The transmitter has 2 binary inputs. They can be defined in field M1 as follows:
Settings of the 4 parameter sets
Example: CIP cleaning
Assignment of field M1 Assignment of binary inputs
M1 = 0 MRS not active. The binary input 1 can be used for external hold.
M1 = 1
The binary input 2 can be used to switch between 2 measuring ranges (parameter
sets). The binary input 1 can be used for external hold.
M1 = 2
The binary inputs 1 and 2 can be used to switch between 4 measuring ranges
(parameter sets). This is the setting used in the following example.
Binary input 1 0 0 1 1
Binary input 2 0 1 0 1
Parameter set 1 2 3 4
Coding /
software field
Medium Beer Water
Alkaline
solution
Acid
M4 Operating mode Conductivity Conductivity Concentration Concentration
M8, M9 Current output 1 ... 3 mS/cm 0.1 ... 0.8 mS/cm 0.5 ... 5% 0.5 ... 1.5 %
M6 Temp. comp. User Tab. 1 linear - -
M5 Conc. tab. - - NaOH User Tab.
M10, M11 Limits on: 2.3 mS/cm
off: 2.5 mS/cm
on: 0.7 μS/cm
off: 0.8 μS/cm
on: 2 %
off: 2.1 %
on: 1.3 %
off: 1.4 %
Coding Field Selection or range
(factory settings bold)
Display Info
M Function group MRS
Settings of remote parameter set switching
(measuring range switching).
M1 + M2: apply to measuring mode.
M3 ... M11: apply to configuration of
parameter sets.
M1 Select binary inputs
1
0, 1, 2
0 = no MRS
1 = 2 parameter sets selectable via binary
input 2. Binary input 1 for hold.
2 = 4 parameter sets selectable via binary
inputs 1+2.
M2
Displays active
parameter set or, if
M1 = 0, select active
parameter set
1
1 ... 4 if M1 = 0
If M1 = 0, selectable.
If M1 = 1 or 2, display depending on binary
inputs.
M3
Select parameter set to
be configured in
M4 ... M8
1
1 ... 4 if M1=0
1 ... 2 if M1=1
1 ... 4 if M1=2
Selection of parameter set to be configured
(the active parameter set is selected in M2 or
with the binary inputs).
