Page #91 background image
Operator’s Manual 41
4 - ETHERNET COMMUNICATIONS
Configuring the Built-in Ethernet Port
The built-in Ethernet port must be properly configured to communicate on a
network or directly with a PC. The Ethernet port has been factory set as follows:
IP Address: 192.168.000.001
Telnet (Set-up) Port: 9999
Web Manager (Set-up) Port: 30718 (Fixed)
Serial Data Port: 10001
The configuration is stored in nonvolatile memory and is retained without
power. The configuration can be changed at any time.
If the IP address or any other setting needs to be changed, the Ethernet port
Setup Mode can be accessed using a Telnet connection, the Web Manager
locally or over the network.
Toconfigurethebuilt‐inEthernetportwithTelnet
1. From your computer Windows desktop, click Start followed by Run
(usually located in the lower right side of the Start Menu).
2. Type the following command: telnet 192.168.000.001 9999
3. Click OK to establish a Telnet connection. The following message
appears:
MAC address XXXXXXXXXXXX (E.g., 00204A808BE8)
Software version V6.3.0.3RC3 (061110) (Version may vary by system)
Press Enter for Setup Mode
4. To enter Setup Mode, press Enter within 5 seconds. The
configuration settings display, followed by the Change Setup menu.
Change Setup:
0 Server
1 Channel 1
5 Expert
6 Security
7 Defaults
8 Exit without save
9 Save and exit Your choice?
5. Select an option on the menu by entering the number of the option
in the “Your choice?” field and pressing Enter.
The two menus recommended for review are “0 Server” and “1
Channel 1”. Bypass the other options listed in the menu.
