NS 5.14 Firmware
4–2 4900002262 rev. B 3-23-21
6. After selecting “0” for Server setup, confirm each value and press
Enter.
7. For “1 Channel 1,” confirm the current value and press Enter. No
parameters under this option need to be changed.
8. When finished, save the new configuration by pressing 9 (Save and
exit) and Enter. The port will reboot after the configuration has been
stored.
Toconfigurethebuilt‐inEthernetportwiththeWebManager
1. Open your web browser and enter the IP address of the built-in
Ethernet port. A login screen will display as shown in Figure 4–1
below.
Under the “0 Server” option, the most commonly changed
parameters include the IP Address and Port No, however, these
are not required to be changed. Please confirm with Service
before changing any other parameters. Refer to “Service
Contact” on page A-4.
Parameters that should never be changed under “1 Channel 1”
include:
• Baudrate (230400)?
• I/F Mode (4C)?
• Flow (00)?
All other Parameters should be left at default values unless the
user is knowledgeable about configuring Ethernet.
Figure 4–1 Login window (Web Manager)
