Engcon EC02 - HS;SW Quick Coupler Overview

3 Design and function
3.3.1. Overview
!
!
EC
!
1
3
2
4
Figure 2.
Position
Description
1
Power supply
2
Alarm indication
3
Indication for open quick coupler
4
Warning lamp
Table 2.
For indications, see section 7.2.1. Indications
