5 Operation
5.8.4. Control system 1 (for machines with double-acting
hydraulic circuit)
Has two functions, tilt and rotation.
Refer to separate user manual supplied on delivery. Also available on
the website or by contacting engcon.
5.8.5. Control system 15 (for machines with double-acting
hydraulic circuit)
Allows simultaneous operation of two functions, tilt and rotation.
Refer to separate user manual supplied on delivery. Also available on
the website or by contacting engcon.
5.8.6. Externally controlled quick coupler lock – SQ/QSC
See separate user manual for quick coupler lock operation.
- SQ – separate locking hydraulics. User manual available from
system supplier.
- QSC – Separate engcon locking system. User manual is available
for download on the website or through direct contact with engcon.
5.9. Changing tools
The following instructions concern general operation of the engcon quick coupler. For
further information and instructions, refer to the separate user manual for the quick
coupler concerned.
To ensure correct operation of the quick coupler lock when connecting/disconnecting a
tools; the quick coupler lock switch must be activated or deactivated and the hydraulics
activated in the proper manner. The procedure for these steps differs between the various
control systems.
5.9.1. Connecting the tool, hydraulic lock
1. Activate the quick coupler lock function.
27
