5 Operation
3. The locking bolts are now in the open position and the
tool is free. Carefully raise the tiltrotator from the tool.
5.10. Fitting and setting up quick coupler locks
DANGER
Check the attachment points regularly and be alert for
the formation of cracks. Risk of personal injury and
damage to property.
WARNING
Beware of moving parts. A lack of awareness may lead
to crush injuries. Risk of personal injury.
Shim the quick coupler and the tool for minimum play. Check that minimum locking wedge
engagement is not below the minimum value:
34
