Engcon EC02 - Quick Coupler Greasing

6 Maintenance
EC20B
EC30
6.4.2. Greasing the quick coupler
Grease quantity: 3-4 pump strokes per nipple.
Grease nipples on both sides, applies to all examples.
The arrows show the location of the grease nipples.
Example, S80
Example, S70
Figure 25.
Figure 26.
Example, HS
Example, ECPUP
Figure 27.
Figure 28.
44
