Engcon EC02 - Special Maintenance Procedures; EC-Oil Special Maintenance

6 Maintenance
6.3. Special maintenance
6.3.1. EC-Oil
Cleaning
- Clean oil connections, electrical
connectors, grease connections and
dirt guards before and after use in order
to avoid oil or grease leakage and
safeguard EC-Oil function.
- If oil or grease leakage occurs despite
cleaning, we recommend face seal
replacement.
- Clean electrical connectors daily and
spray with water repellent.
Figure 22. Bildtext
Replacing face seals
Applies to hydraulic connectors on quick
couplers.
1. Remove the existing face seal with the
aid of a sharp tool.
2. Carefully fit the new face seal by hand.
ECO45/50 Face seal ECO
3/8" (1052976)
ECO60 Face seal ECO 1/2" (1050018)
ECO70 Face seal ECO 3/4" (1050580)
Figure 23.
41
