Engcon EC02 - Integrated Grabber Lubrication (GR10;GR20); Integrated Grabber Lubrication (GR20 RR)

6 Maintenance
6.4.3. Lubrication, integrated grabber GR10, GR20
Grease quantity: 3-4 pump strokes per nipple.
The arrows show the location of the grease nipples.
Figure 29.
6.4.4. Lubrication, integrated grabber GR20RR
Grease quantity: 3-4 pump strokes per nipple.
The arrows show the location of the grease nipples.
Figure 30. Bildtext
45
