5 Operation
WARNING
When lifting, make sure the load burdens both grab
arms. Make sure the load cannot shift and only burden
one grab arm. When all force is exerted by only one
arm, the grab is at risk of opening. Risk of injury and
property damage.
Figure 15.
Bildtext
5.4. Hydraulic hammers
The use of hydraulic hammers together with the tiltrotator causes increased wear.
5.5. Augers
The use of augers together with the tiltrotator causes increased wear. The worm gear is
designed for slow-moving, short operations. In some cases, it can cause the worm gear to
overheat. Prolonged rotation, as with an auger, should be avoided
IMPORTANT
Avoid rotation for extended periods; it can cause the worm gear
to overheat. Risk of property damage.
5.6. Pallet forks
When using pallet forks, the tiltrotator's cylinders must be fitted with hose break valves. If
uncertain, contact your supplier.
To avoid overloading the quick coupler locking pins, the pins must be turned away from
the forklift tines.
WARNING
The excavator arm system cylinders must be fitted
with valves to prevent the load from dropping in the
event of a hose failure. Risk of personal injury and
damage to property.
25
