4 Installation
DANGER
Do not exceed tipping load limits. The weight of the
product and the increased reach may impair stability.
Risk of personal injury and damage to property.
WARNING
If you have any doubts concerning the safety aspects
of your knowledge, the equipment or work, contact
a dealer or engcon Nordic AB. Incorrect installation
affect safety.
IMPORTANT
Assembly and installation may only be carried out at a
workshop authorized by the manufacturer. Changes to the
assembly may not be carried out without the manufacturer’s
consent.
4.3.1. Attaching the tiltrotator
1. Check the tipping load limits. Take tiltrotator weight
and the extended risk area into account. Installation may
entail a necessary reduction in the volume of the tool.
2. Position the base machine and the tiltrotator on a flat,
non-slip surface. Make sure the tiltrotator is upright and in
line with the stick and dog bone linkage.
3. If necessary, use a firmly planted ladder.
19
