8 Decals
8. Decals
Machine instructions, decals and warning signs must be kept clearly legible. Contact your
supplier to order replacements.
WARNING
Replace damaged or illegible signs and decals before
using the machine. Risk of personal injury and
damage to property.
8.1. Decal disposition
8.1.1. Control systems 9 and 10
For decals, refer to separate user manual supplied on delivery.
8.2. Warning decals
The decals are usually placed to the right of the operator in clearly visible locations.
8.2.1. Warning decals in cab
8.2.1.1. 9000353
WARNING
Important.
Subtract tiltrotator weight
when calculating lifts.
9000353-A
Figure 33. Place the warning decals next to the base machine’s load diagram.
