5 Operation
Quick coupler S30-S80
Quick coupler S1-S3
Figure 16.
Figure 17.
Quick coupler
A (max)
S30
0.2 inch
S40
0.39 inch
S45
0.39 inch
S50
0.39 inch
S60
0.79 inch
S70
0.87 inch
S80
0.98 inch
Table 4.
Quick coupler
A (min)
S1
1.2 inch
S2
1.2 inch
S3
1.2 inch
Table 5.
