5 Operation
Quick coupler CW10-45
Quick coupler HS
Figure 20.
Figure 21.
Quick coupler
A (max)
CW10-45
A ≥ B * 0.75
Table 8.
Quick coupler
A (max)
HS08
0 to 0.55 inch
HS10
0 to 0.2 inch
HS20/21/25
0.39 to 0.2 inch
Table 9.
37
