9 Technical data
Description
EC02
EC05B
EC10B
EC15B
EC20B
EC30
Rec open/close
pressure SQ Q-
Safe
psi
NA
NA
NA
NA
NA
3050
Weight
lbs*
170
357
655
853
1,367
1790
Width (A)
inch*
7.1
10.2
12.6
12.6
17.7
19.7
Width (B)
inch*
6.1
8.5
9.6
11.2
11.8
15.4
Width (C)
inch*
6.3
6.3
11.4
12.1
12.2
15.4
Overall length (D)
inch*
17.1
19.1
21.3
27.5
35.0
38.2
Construction height
(E)
inch*
from 9.6
from 11.8
from 15.4
from 16.5
from 17.3
from 20.5
Swivel channel
extra function,
number of ports
2
2
2 (4)
2 (4)
2 (4)
2 (4)
Swivel channel
locking function,
number of ports
2
2
2
2
2
2
Rotation
Unlimited
Unlimited
Unlimited
Unlimited
Unlimited
Unlimited
Tilt angle
°
2x40
2x40
2x40
2x40
2x40
2x40
Tilt duration under
hydraulic flow
s / gal/
min
3/2
3/4
3/8
3/9
3/17
3.5/22
Rotation duration
for one rotation
under hydraulic
flow
s / gal/
min
7/5
6.5/8
7/11
7/13
7/18
7/21
Table 21.
*Standard attachment
** [l/min] with High Flow
