7. Product Description CC300 Operator Panel – User Guide
7. Product Description
The CC300 operator panel is a Human Machine Interface (HMI) system designed for demanding industrial
applications. As a workstation system with integrated touch screen display it is designed for installation in
an instrument panel or other cabinets. For better handling and readability the operator panel can be tilt
continuously out of its vertical position up to a maximum tilt angle of 45 degrees by a linear actuator
(outwards, with the lower edge ahead).
Das CC300 operator panel consists of two main parts, the front plate and the rear cover.
The front of the CC300 operator panel is designed in glass; between the glass and the 21.5"display a PCAP
touch (capacitive touch with multi-touch capability) is laminated on the glass. In addition, the glass front
supports an emergency stop switch, an RFID antenna, capacitive buttons with LED backlight and a
rotary/push button with LED backlight.
The rear cover consists of die cast aluminum and serves the following functions: Heat sink of the system,
chassis for assembling of electronic modules, holder of the linear actuator (of the external tilting
mechanism) and cable gland for all outgoing cables.
The CC300 operator panel accommodates an INTEL processor architecture board that will host the “LINUX
64 Bit” operating system. All components, hardware and hardware drivers are designed to support 100%
the “ENGEL LINUX x86 64 Bit” operating system. An mSATA drive is installed as storage device. Optionally,
the CC300 operator panel can be equipped with a 2.5" SSD or HDD drive.
The CC300 operator panel has two externally accessible USB 2.0 ports located at the left side of the
chassis. The position of the USB ports is marked on the front plate with backlit symbols.
The CC300 operator panel provides two external LAN ports. Thus, it can be connected simultaneously e.g.
to the corporate LAN and to a stored program control (SPC).
Via the RFID read/write zone at the glass front of the CC300 operator panel e.g. smart cards can be read or
written contactless.
The CC300 operator panel is designed for 24V DC operation.
The CC300 operator panel will not meet any safety functions!
Monitoring of all safety-related components (emergency stop, protective covers etc.) will
be performed by particular safety modules of the terminal equipment.
16 Preliminary Version 0.2
