9. Technical Data CC300 Operator Panel – User Guide
9. Technical Data
CC300 Operator Panel Technical Data
System Customer-specific HMI panel PC with glass front
Operating System ENGEL LINUX x86 64bit
Cooling Concept Fanless system
Cabinet Front: glass front with aluminum frame, Rear: die cast aluminum cover
Protection Class IP 54 (entire system)
Power Supply 24 V DC (see also chater 9.2 “Electrical Specifications”)
External Interfaces See chapter 9.1 “External Connectors and Interfaces”
Display TFT LCD Display, 21.5", 1920x1080, 16:9 portrait format, multi-touch,
contrast: 400:1, 16 million colors, brightness: 250 cd minimum, LED
backlight, view angle: 85x85x85x85 minimum
Optionally, an additional external display can be connected via DP cable
Touch Screen Capacitive PCAP multi-touch
RFID EM65 (Euromap Standard RFID ISO15693), 13.56 Mhz, read and write
functionality, implementation for user login
Emergency Stop Switch Four (optional: six) emergency stop circuits (24V break circuits), switch is
self-locking and can only be unlocked by turning the button
Front Glass Clear glass, thermally tempered, thickness: 5mm (+/- 0.2 mm), printed on
the rear side, 5 capacitive buttons integrated in the glass, LED backlight for
buttons and symbols
Buttons in the Glass Front Capacitive buttons (milled in the front glass) with LED backlight, partly with
software-controlled color change when pressed
Rotary/Push Button Can be adjusted to the left/right to a maximum of 30 degrees, self-resetting
when released, push button function, white backlit ring that can change its
color to red, green and orange by software
Mainboard Kontron SBC-754
CPU Intel Celeron 847E
Memory 2GB (1 socket, SO DIMM, DDR3, 1.066 MHz)
Drives 1x mSata, 8GB (optional: 2.5" HDD/SSD via SATA, drive bay available)
LAN 2x Ethernet 10/100/1000
IO Board B750 IO board, reverse voltage protection and short circuit protection
38 Preliminary Version 0.2
