Engel CC300 - Left and Right Side View

7. Product Description CC300 Operator Panel – User Guide
7.3. Left and Right Side View
Fig. 21: Right side of the CC300 operator panel
Fig. 22: Left side of the CC300 operator panel
Legend for Fig. 21 and Fig. 22:
1 Emergency stop switch
2 Front plate of the CC300
3 Aluminum rear cover of the CC300
4 Rotary/push button
5 Screws that secure the rear cover at the front
plate
6 Cable gland
7 Cavity with 2x USB 2.0 ports
