Engel CC300 - Environmental Specifications; Mechanical Specifications

9. Technical Data CC300 Operator Panel – User Guide
9.3. Environmental Specifications
Thermal Management Passive Cooling (CPU and entire system)
Operating Temperature +5 °C to +50 °C (41 °F to 122 °F)
Storage/Transit Temperature -30 °C to +80 °C (-22 °F to 176 °F)
Operating Rel. Humidity 5% to 95%, non-condensing
Storage/Transit Rel. Humidity 5% to 95%, non-condensing
Operating Altitude 0 m to 2000 m (0 ft. to 6560 ft.)
Storage/Transit Altitude 0 m to 10000 m (0 ft. to 32800 ft.)
Operating Shock 15 G, 11 ms duration, half-sine
Storage/Transit Shock 30 G, 11 ms duration, half-sine
Operating Vibration 5 Hz to 150 Hz, 0.5 G
Storage/Transit Vibration 5 Hz to 150 Hz, 1.0 G
Protection Class IP54 (entire system)
9.4. Mechanical Specifications
Dimensions CC300 Operator Panel
Height
675 mm (26.57")
Width
346 mm (13.62")
Depth
76 mm (2.99")
Weight
13 kg (28.66 lbs)
Preliminary Version 0.2 41
