Engel CC300 - External Connectors and Interfaces

9. Technical Data CC300 Operator Panel – User Guide
9.1. External Connectors and Interfaces
Interface Amount Position Data
LAN cable
2 external
 Type: 10/100/1000 Mbit
 Connector: RJ45
 Source: CPU board
DP cable
optional
1 external
 Type: Display port
 Connector: DP (DisplayPort)
 Source: CPU board
Power cable
1 external
 Type: Power Connector Main
 Connector: Harting 24-pin
 Source: I/O board
Expansion Panel cable
1 external
 Type: Control RS485
 Connector: DSUB
 Source: I/O board
Expansion Panel cable
1 external
 Type: Power
 Connector: 4-Pin
 Source: I/O board
Emergency Stop circuits
1 external
 Type: Control
 Connector: 8 wires in Harting connector
 Source: Emergency Stop switch
USB Port
2 external
 Type: USB 2.0
 Connector: USB A
 Source: CPU board
Grounding (PE) cable
1 external
 Type: PE
 Connector: End-sleeve
 Source: Chassis internal PEN
Preliminary Version 0.2 39
