Engel CC300 - Electrical Specifications

9. Technical Data CC300 Operator Panel – User Guide
9.2. Electrical Specifications
CC300 Operator Panel Electrical Data
Power Supply 24VDC (+/- 20%), 3.5A max.
Component Theoretical Value (Measured Value)
CPU Board B754
(including CPU 847E) 27 W
LCD Panel 23 (16) W
SSD 2x 3 W
I/O-Board 2 W
RFID 1 W
Rotary/push button 2 W
USB external 2x - power 0.5 W
Total dissipated internal 58.5 (51.5) W
USB external 2x 5 W
Linear actuator CAHB 44 (36) W
Total input power
(including all possible loads)
107.5 (92.5) W
40 Preliminary Version 0.2
