S-Play User Manual
Part No.: 51301
8 October 2020
(v23)
Document ID: 4686708 Page|14
Connection to Relays
The S-Play contains relays designed for use with low power devices and to provide switching
logic for higher power devices.
To ensure a safe installation it is imperative that the power connected to the S-Play relays is
within safe operating limits:
The S-Plays relay specifications are as follows:
Maximum Current Rating: 2A
Maximum Voltage Rating: 50V DC
Total switchable power of each S-Play relay: 60W.
To calculate to total power your circuit will pass through the relay, multiply the circuit
voltage by the current you intend to pass through it. This value must be lower than 60w
Example 1
Example 2
Example 3
Current
1.2A
2A
2A
Voltage
50V
30V
50V
Maximum Power
60W 60W 100W
If your application requires mains power switching or high current applications, ENTTEC
recommends the use of a DMX switch pack controlled by the S-Play’s DMX output, or wire the
S-Plays relay outputs to connect to the primary coil of a DIN mount high powered relay.
