Initial Installation
QUALIFIED INSTALLERS ONLY
exhaust RestRictoR setting:
When installing the C60I it may be necessary to add a restrictor in the rebox to control the combustion
and ame appearance. the exhaust restrictor ring kit is included in the manual bag, to install the exhaust
restrictor the safety screen assembly and glass door must be removed, see the Maintenance and Service
section [Page 15, 16, and 17]. There are six dierent restrictor sizes, make sure you install the correct
size. See gure 41 & 42 for possible vent congurations and the corresponding restrictor setting. Proper
Install is crucial to a ecient replace burn and the best possible looking ame.
Figure 43. Restrictor Install
60%
Wing Nuts x3
50%40%
30%
20%
10%
Note: There are six dierent
restrictor sizes, they are marked
with retangular holes which
coincide with the percentage of
restriction (Figure 44).
Figure 44. Restrictor Ring Kit
