Secondary Installation
Log set instaLLation:
The placement of the logs is not arbitrary. If they are positioned incorrectly, the ames can be impinged and
will not burn correctly. See the instructions included with 50-3347 Log & Rock set for more detail. NOTE:
The logs are fragile and should be handled gently.
1. Position Log #1 in the back left corner; the log will butt up to both the side and rear panels. Place the
Log #2 into the back right corner; the log will butt up to both the side and the rear panel.
2. Position Log #3 over top the burner; there should be 3 points of interest to help position this log.
Make contact with the left liner, the rear liner, and the rebox edge opening.
3. Position Log #4 underneath Log#3 along the front media strip. Place the charred end toward the
burner as shown.
4. Position Log #5 on the Log #3 alignment pin. Bring the other end close to the rebox opening.
