Epec 6107 - Page 48

Technical Manual &
Cabling Instructions
Page 48 / MAN000596
Approvals and Safety
Epec Oy reserves all rights for improvements without prior notice
Epec Oy
Tiedekatu 6
FIN-60320 Seinäjoki
Postal address
PL/P.O.Box 194
FIN-60101 Seinäjoki,
Finland
Phone
+358-(0)20-7608 111
Fax
+358-(0)20-7608 110
Internet
www.epec.fi
AM 80% 1 kHz,
Dwell time 2 s
2700-
6000
3 V/m
Electrical fast transient (EFT/B)
immunity test
• Test method EN 61000-4-4
• Performance criterion B
Test pulse Port Test level
Repetition
frequency 5 kHz,
Duration 1
minute
DC input
port
± 2,0 kV
Signal
ports
± 1,0 kV
Surge Immunity
• Test method EN 61000-4-5
• Performance criterion B
Specification
Port
Path Test
level
Pulses: 5
Repetition rate:
60 s
DC
Input
port
Line to
Line
± 0,5
kV
Line to
Ground
± 0,5
kV
Electrostatic discharge (ESD)
immunity test
• Test method EN61000-4-2
• Performance criterion B
Discharge mode
Test level (kVp)
Contact
± 2, ± 4, ± 6, ± 8 (Note 1)
Indirect contact ± 2, ± 4, ± 6, ± 8
Air ± 2, ± 4, ± 8, ± 15
Note 1: WLAN SMA connector tested with ± 2 kV
Performance criteria for immunity tests
Performance criterion A:
The EUT shall continue to operate as intended during and after the test. No degradation of
performance is allowed.
Performance criterion B:
The EUT shall continue to operate as intended after the test. However, moderate degradation
of performance is allowed. No change of actual operating state or loss of memory functions is
allowed.
