Epson EB-G7200W User Manual

Submenu Function
Display
You can make settings related to the projector's display.
Menu Position: Select the position to display the menu on
the projected screen.
Message Position: Select the position to display the message
on the projected screen.
Messages: When set to Off, the following items will not be
displayed.
Item names when the Source, Color Mode, or Aspect is
changed, messages when no signal is being input, and
warnings such as High Temp Warning.
Display Background
*2
: You can set the screen status for
when no image signal is available to Black, Blue, or
Logo.
Startup Screen
*2
: Set to On to display the User's Logo
when projection starts.
Standby Confirmation: (This is unavailable when the
Remote Control Type is set to Simple.) If it is set to Off,
you can turn off the power simply by pressing the [t]
button once.
Air Filter Notice: You can set whether or not (On/Off) to
enable Air Filter Notice. When this is set to On and a clog
in the air filter is detected, the message is displayed on the
screen.
Screen: (This setting is unavailable when projecting images
from a computer over a network.) Set the aspect ratio and
position of the projected screen according to the type of
screen being used.
s "Screen Settings" p.30
Panel Alignment: Correct color misalignments (red and
blue) in the screen.
s
"Panel Alignment" p.199
Color Uniformity: Adjusts the color tone balance for the
whole screen.
s "Color Uniformity" p.200
OSD Rotation: Rotates the menu direction by 90 degrees.
Submenu Function
User's Logo
*2
You can change the user's logo that is displayed as a
background during Display Background, A/V Mute, and so
on.
s "Saving a User's Logo" p.120
Projection
Select from one of the following projection methods
depending on how the projector is installed.
Front, Front/Ceiling, Rear, and Rear/Ceiling
You can change the setting as follows by pressing down
the [A/V Mute] button for about five seconds.
FrontWFront/Ceiling
RearWRear/Ceiling
Direction
Set this parameter according to the installation status of the
projector.
*3
s "Installation Settings" p.28
For portrait installation, set Portrait Mode to On.
List of Functions
143

Epson EB-G7200W Specifications

General

Number of colors	1.07 billion colors
Native aspect ratio	16:10
Projection distance	- m
Projection technology	3LCD
Contrast ratio (typical)	2000:1
Screen size compatibility	50 - 300 \
Projection distance (tele)	2.5 - 15.1 m
Projection distance (wide)	1.5 - 9.4 m
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-45 - 45 °
Keystone correction, horizontal	-30 - 30 °
Lamp power	400 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
Service life of light source (portrait mode)	2000 h
Full HD	No
HD-Ready	Yes
Video processing	10 bit
Video color modes	Cinema, Dynamic, Presentation, sRGB, DICOM simulation mode, Multi-projection
Analog signal format system	-
Supported graphics resolutions	1280 x 800 (WXGA)
Throw ratio	1.44 - 2.33:1
Focal length range	24 - 38.2 mm
Aperture range (F-F)	1.7 - 2.3
Vertical lens shift range	-67 - 67 %
Horizontal lens shift range	-30 - 30 %
Audio (L/R) in	3
Audio (L/R) out	1
Serial interface type	RS-232
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Noise level	39 dB
Country of origin	China
Noise level (economic mode)	31 dB
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	White
Market positioning	Presentation
Cable lock slot type	Kensington
RMS rated power	10 W
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	572 W
Power consumption (PowerSave)	477 W
Storage temperature (T-T)	-10 - 60 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet width	800 mm
Pallet height	2425 mm
Pallet length	1200 mm
Pallet weight	0 g
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	14 pc(s)
Quantity per pallet layer	2 pc(s)
Harmonized System (HS) code	85286200
Software support	via: AMX, Crestron (Network), Control4

Weight and Dimensions

Depth	472 mm
Width	525 mm
Height	189 mm
Weight	12700 g
Package depth	765 mm
Package width	680 mm
Package height	290 mm
Package weight	20740 g
