Epson EB-G7200W User Manual

Submenu Function
HDBaseT
Control Communications: (This cannot be set when
Extron XTP is set to On.) When set to On, Ethernet
communication, serial communication, and the wired
remote control through the HDBaseT Transmitter connected
to the HDBaseT port are all enabled.
Extron XTP: Set to On when you connect the Extron XTP
transmitter or switcher to the HDBaseT port. See the
following Extron Web site for more details on the XTP
system.
http://www.extron.com/
a
• When Control Communications or Ex‐
tron XTP is set to On, Standby Mode is
automatically set to Communication On.
• When Control Communications or Ex‐
tron XTP is On, the projector's LAN
port, RS-232 port, and Remote port are
disabled.
• When Extron XTP is set to On, the fan
may rotate in standby mode but this is
not abnormal.
Submenu Function
Multi-Projection
Make settings when projecting from multiple projectors.
s "Multi-Projection Function" p.102
Projector ID: Set the ID from 1 to 30. Off indicates that no
ID is set.
s "ID Settings" p.41
Tiling: Set the number of split screens and positions of each
projected image.
s "Tiling" p.111
Geometric Correction: Corrects distortion in the projected
image.
s "Correcting Distortion in the Projected Image" p.62
Edge Blending: Corrects a border between multiple images
to create a seamless screen.
s "Edge Blending" p.102
Scale: When using multiple projectors to project one image,
adjust the range of the image displayed by each projector.
s "Displaying a Scaled Image" p.112
Color Mode: Set to Multi-Projection.
Brightness Level
*1
: When the brightness of each lamp
differs, set the lamp brightness level. This item can be
adjusted only when Power Consumption is set to Off from
the Settings menu.
s "Correcting the Brightness (EB-G7905U/EB-G7900U/EB-
G7500U/EB-G7200W/EB-G7000W/EB-G7805/EB-G7800/EB-
G7100 only)" p.105
Color Matching: Corrects the difference between the tint
and brightness of each projected image.
s "Color Matching" p.106
Color Uniformity: Adjusts the color tone balance for the
whole screen.
s "Color Uniformity" p.200
RGBCMY: You can adjust the Hue, Saturation, and
Brightness for R (red), G (Green), B (Blue), C (Cyan), M
(Magenta), and Y (Yellow) color components.
s "Adjusting RGBCMY" p.107
List of Functions
146

Epson EB-G7200W Specifications

General

Number of colors	1.07 billion colors
Native aspect ratio	16:10
Projection distance	- m
Projection technology	3LCD
Contrast ratio (typical)	2000:1
Screen size compatibility	50 - 300 \
Projection distance (tele)	2.5 - 15.1 m
Projection distance (wide)	1.5 - 9.4 m
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-45 - 45 °
Keystone correction, horizontal	-30 - 30 °
Lamp power	400 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
Service life of light source (portrait mode)	2000 h
Full HD	No
HD-Ready	Yes
Video processing	10 bit
Video color modes	Cinema, Dynamic, Presentation, sRGB, DICOM simulation mode, Multi-projection
Analog signal format system	-
Supported graphics resolutions	1280 x 800 (WXGA)
Throw ratio	1.44 - 2.33:1
Focal length range	24 - 38.2 mm
Aperture range (F-F)	1.7 - 2.3
Vertical lens shift range	-67 - 67 %
Horizontal lens shift range	-30 - 30 %
Audio (L/R) in	3
Audio (L/R) out	1
Serial interface type	RS-232
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Noise level	39 dB
Country of origin	China
Noise level (economic mode)	31 dB
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	White
Market positioning	Presentation
Cable lock slot type	Kensington
RMS rated power	10 W
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	572 W
Power consumption (PowerSave)	477 W
Storage temperature (T-T)	-10 - 60 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet width	800 mm
Pallet height	2425 mm
Pallet length	1200 mm
Pallet weight	0 g
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	14 pc(s)
Quantity per pallet layer	2 pc(s)
Harmonized System (HS) code	85286200
Software support	via: AMX, Crestron (Network), Control4

Weight and Dimensions

Depth	472 mm
Width	525 mm
Height	189 mm
Weight	12700 g
Package depth	765 mm
Package width	680 mm
Package height	290 mm
Package weight	20740 g
