Using ESC/VP21 Commands

157

Signal name Function

GND Signal wire ground

TD Transmit data

RD Receive data

Communications protocol

• Default baud rate setting: 9600 bps

• Data length: 8 bit

• Parity: None

• Stop-bit: 1 bit

• Flow control: None
