Epson EB-PU2010B User Manual

Multi-Projection Features
117
You can combine the projected images from multiple projectors to create one
bright image or a large seamless image.
By using the auto adjustment function that uses the optional external camera
and the Epson Project Professional Tool software you can perform virtually
adjustment-free operation.
a
You can download the Epson Projector Professional Tool software and
its manual from the following website.
epson.sn
gg Related Links
• "Procedure Overview" p.117
• "Preparation" p.117
• "Image Composition" p.119
• "Adjusting Colors" p.120
Procedure Overview
This section explains the recommended procedure for using the optional
external camera and the Epson Projector Professional Tool software.
Preparation
• Initializing projectors
• Assigning a master projector
• Calibrating projectors
• Installing projectors
• Performing rough image adjustments
• Connecting projectors to a network
Image Composition
• Tiling
• Stacking
Adjusting colors
Preparation
This section explains how to perform basic settings before installing the
projector and preparing in advance for easier operations later.
You can setup up to 15 projectors to project one large image by compositing
several images (tiling) and up to 6 projectors to project a bright image by
overlaying images (stacking).
gg Related Links
• "Initializing Projectors" p.117
• "Assigning a Master Projector" p.118
• "Calibrating Projectors" p.118
• "Installing Projectors" p.118
• "Performing Rough Image Adjustments" p.118
• "Connecting Projectors to a Network" p.119
Initializing Projectors
You need to correct the difference in settings for each projector.
Do the following operations for all projectors:
• Reset the projector settings to their default values.
s Reset > Reset All Config
• Reset the values on the Color Uniformity menu to their default settings.
s Extended > Display > Color Uniformity > Reset
• Reset the values on the Panel Alignment menu to their default settings.
s Extended > Display > Panel Alignment > Reset
• Set the Adjustment Level setting to All in the Color Matching menu, and
select 0 for Red, Green, and Blue.
s Extended > Multi-Projection > Screen Matching > Color Matching
a
We recommend you set the Sleep Mode setting to Off in the
projector's Extended menu after all initialization is complete.
gg Related Links
• "Sleep Mode" p.92

Epson EB-PU2010B Specifications

General

Matrix size	1.03 \
Heat dissipation	1819 BTU/h
Number of colors	1.07 billion colors
Native aspect ratio	16:10
Projection technology	3LCD
Contrast ratio (typical)	2000:1
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Keystone correction, vertical	-45 - 45 °
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	7000 ANSI lumens
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Throw ratio	0.35 - 7.41:1
Focal length range	varies by lens mm
Interchangeable lens	Yes
3D	No
Video processing	10 bit
Video color modes	Cinema, Dynamic, Natural, Presentation, DICOM simulation mode, Multi-projection, BT.709
Analog signal format system	Not supported
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Noise level	37 dB
Preset modes	Cinema, Presentation, Dynamic
Country of origin	Philippines
Noise level (economic mode)	30 dB
Placement	Ceiling, Desktop, Flying frame
Product type	Large venue projector
Product color	Black
Market positioning	Business
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	535 W
Power consumption (economy mode)	452 W
Storage temperature (T-T)	-10 - 60 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Bundled software	Inhalt DIY-App, EasyMP Multi PC Projection, Epson Projektor Content Manager, Epson Projektor Management, Epson Projektor Professional Tool
Supported network protocols	HTTPS, IPv6, SNMP, ESC/VP.net, PJLink
Software support	via: Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	14 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	436 mm
Width	545 mm
Height	189 mm
Weight	16800 g
Package depth	765 mm
Package width	570 mm
Package height	270 mm
Package weight	21876 g
